🚀 VLSI Physical Design Mock Interview | RTL to GDSII | Advanced Nodes

Are you preparing for a VLSI Physical Design Engineer interview and wondering what real semiconductor companies expect?

Join a mock interview session designed from my hands-on industry experience working on RTL-to-GDSII implementation across multiple technology nodes including 32nm, 28nm, 12nm, 5nm, 3nm, and 2nm.

In this session, we will cover:

🔹 Physical Design Fundamentals

• Floorplanning & Power Planning

• Placement & Optimization

• CTS & Routing concepts

• ECO implementation strategies

🔹 Timing & Signoff Concepts

• STA (Setup/Hold) analysis

• Timing closure techniques

• SI/Noise debugging

• Real-world violation fixing approaches

🔹 Physical Verification & Reliability

• DRC & LVS debugging

• EMIR concepts

• Signoff challenges

🔹 Interview Preparation

• Industry-level technical questions

• Scenario-based problem solving

• Resume discussion

• Feedback & improvement areas

• Career guidance for freshers and experienced engineers

Having worked on advanced technology nodes and successful silicon tapeouts, I’ll help you understand not only textbook concepts but also how Physical Design problems are solved in real chip projects.

Let’s bridge the gap between learning VLSI and building silicon 🚀
